Autel MaxiCOM MK808TS MK808S-TS MK808Z-TS TPMS Tool for Relearn Programming With 30+ Service All Systems Diagnosis Functions Ship from US Distributor

: In stock

: Auto Diagnostic & TPMS Tool

: Autel

Regular price $599.00 $599.00

Highlights:1. Combination of Autel MK808BT and TS6012. With Complete TPMS and Sensor Programming3. OE-Level TPMS Scan Tool with 28+ Service Functions4. One...
$599.00

QUESTIONS & ANSWERS

Have a Question?

Be the first to ask a question about this.

Ask a Question
Highlights:

1. Combination of Autel MK808BT and TS601
2. With Complete TPMS and Sensor Programming
3. OE-Level TPMS Scan Tool with 28+ Service Functions

4. One Year Free Update Online on Autel Official Website (After One Year, Update Cost 349USD/Year)
5. Relearn Parking Brake Pad Position After Replacement; Supports forced diesel particulate filter regeneration and injector adjustments
6. Vehicles Supported: Support Asian and European vehicles after 1996, Auto VIN technology automatically identifies the vehicle's make, model and year
7. Support Multi-Language: English, French, German, Spanish, Portuguese, Dutch, Polish, Swedish, Korean, Japanese, Russian, Italian (If you need to change device languge, please send us serial number. We can authorize other language online)
8.Ship from US Distributor

Notice:

1. Support Programming Autel MX-Sensor Only, Other Brands Sensors are not valid
2. Language Authorization: You can not change language yourself on tablet. If you would like to change language for your tablet, please kindly share us your device serial number first. we will help to authorize the language you need online first.

BULLET POINTS

1. Feature-Rich Software: Compared with Autel MX808 and MK808BT, this diagnostic scanner is equipped with more comprehensive and superior diagnostic functions including full systems diagnoses and Oil/EPB/BMS/SAS/DPF Reset, etc.
2. Advanced Hardware: This Autel scanner offers VCI box for Bluetooth connection without the hassle of length limitation on obd2 cable, and it’s still built with the high-end Cortex-A9 processor, Android OS and 32GB memories for improving diagnostic efficiency.
3. Gread Performance: You'll get to save on time since Autel MaxiCOM MK808TS works very fast. It comes equipped with a Cortex A9 processor which is popular for performing tasks quickly.It comes with a 32GB memory card which eliminates the need of installing any external source of hardware to expand the memory.The battery is also quite powerful and easily runs for 5-7 hours of continuous use.
4. TPMS FUNCTIONS: Autel MK808TS is specially designed to provide the complete TPMS service as MaxiTPMS TS608 including TPMS health check, programming and relearn etc., for helping technicians to quickly find out the faulty sensor and turn off the MILs related.
5. SPECIAL SERVICES: This full-system scan tool provides the most commonly-performed capabilities including Oil reset, EPB/ SAS/ BMS/ DPF service as MaxiCOM MK808 & MX808TS does, to meet users' demand for efficient repairs.
6. ALL SYSTEM DIAGNOSES: Besides featuring the quick and precise full OBDII functions, this automotive diagnostic scanner can also work on all available system modules in vehicles for technicians to diagnose complex problems accurately.

Description:

Autel MaxiCOM MK808TS is a powerful and intuitive seven-inch touchscreen Android tablet capable of scanning all available system for faults and aiding in performing an extensive list of the most popular maintenance services including oil and service light resets and steering angle sensor calibration. The tool's quad-core processor and 32 gigabyte operating memory combined with its drill-down touch interface enables deft analysis of domestic, Asian and European vehicles, 1996 and newer.

Autel MK808TS, as a professional Android-based car diagnostic scanner combined with MK808 and TS601, features all-around fixes of 21 different service functions, comprehensive TPMS services, as well as full systems diagnoses. With accurate analysis, fast operation, and ease of use feature, this Autel scanner is ideal for both first-timers and professional mechanics.

Advanced Hardware to Facilitate Your Repair Work

Except its widely-used software, the advanced hardware also brings glory to Autel MK808TS's mooth and fast operation.
1. Android 4.4.4-based tablet diagnostic tool greatly improves the working efficiency with performance and power optimized 1.5GHZ Cortex-A9 Processor.
2. 7 inch touchable LCD screen with 1024*600 resolutions offers ultra-clear visuals of the diagnostic data, making it easy to navigate and read codes.
3. 1GB RAM DDR3 / 32GB On-Board ROM Memory is not only an extended storage space but a way to reduce the possible issue of slow response.
4. Built-in 5000 mAh battery provides up to 7 hours continuous battery life for giving you a worry-free operation experience.
5. MaxiVCI Mini is equipped for connecting between the diagnostic tablet and DLC for wirelessly vehicle data transmission via the fast and reliable Bluetooth 2.1 EDR, allowing technicians to have complete freedom to move anywhere in the repair shop when the VCI is connected to the car.

Features

1. Extensive vehicle coverage for more than 80 US, Asian and European vehicle makes and models
2. Exceptional OE-level system coverage for all electronic systems
3. Complete capabilities for codes, live data, ECU information, adaptation, matching, etc.
4. Auto VIN technology can automatically identify the vehicle's make, model and year information in no time
5. Automatic system and software updates with real-time push message notifications via Wi-Fi
6. Instant remote control tech support anytime, anywhere
7. Advanced TPMS diagnostics with DTC description
8. TPMS status, one step for complete TPMS health check
9. Activate 98% of all known TPMS sensors
10. Program AUTEL MX-Sensor
11. Comprehensive OBD relearn coverage
12. On-screen relearn procedure
13. One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized
14. Cloud-based MaxiFix online community provides a vast database of diagnostic and and proven filed fixes

Widespread Coverage for Multiple Vehicle Models

The best part about the MK808TS is its wide vehicle coverage. It is compatible with most 1996 US-based vehicles or newer, and 2000 EU-based vehicles or newer. In other words, it supports a wide range of modules that can be scanned for codes as well as the ability to display values and sensor data for the specific module scanned.

Asia:
For Acura, For Daewoo, For Holden, For Honda, For Hyundai, For Infiniti, For Isuzu, For Kia, For Lexus, For Mazda, For Mitsubishi, For Nissan, For Scion, For SsangYong, For Subaru, For Suzuki, For Toyota, For BYD, For ChangAn, For Chery, For DFM, For FAW, For Foton, For Geely, For GreatWall, For Haval, For JAC, For Lifan, For Luxgen, For MG, For Zotye

Europe:
For Abarth, For Alfa-Romeo, For Alpina, For AstonMartin, For Audi, For Bentley, For Benz, For BMW, For Citroen, For Dacia, For Ferrari, For Fiat, For Jaguar, For Lamborghini, For Lancia, For LandRover, For Lotus, For Maserati, For Maybach, For Mini, For Opel, For Peugeot, For Porsche, For Renault, For Rolls-Royce, For SAAB, For Skoda, For Smart, For Volvo, For Volkswagen

USA:
For Buick, For Cadillac, For Chevrolet, For Chrysler, For Dodge, For Ford, For GMC, For Hummer, For Jeep, For Lincoln, For Mercury, For Oldsmobile, For Pontiac, For Saturn, For Tesla


Functions Supported:

1. All Systems Diagnoses for Deep Inspection in Vehicles

MK808TS is a full system diagnostic scanner that can quickly test every system module's status and make faster diagnosis & maintenance via reading/clearing codes as well as viewing live data etc., but only costs you a few minutes to finish full scanning. You can learn to perform complex diagnostic functions with that will give you a lot more power over the ins and outs of your car to figure out what is going on with your modern computerized vehicle, so that you can get it fixed and get back on the road in due time.

1). For Engine System: Diagnostic tool MK808TS can help detect the engine ignition, fuel injection, air and fuel ratio, and exhaust emission conditions in Engine system to enhance vehicle performance, save energy and reduce exhaust emission.
2). For Transmission: It makes great sense in the safety driving when your car is slipping or difficult to shift, this diagnostic tool can figure the problems out via reading codes in the Transmission system, or check the health status via live data viewing.
3). For ABS System: Diagnosing an ABS problem should always start with a visual inspection of all brake components, next you will need to retrieve ABS codes to tell you where the problem is, and this is what this diagnostic does for you.
4). For SRS System: SRS, safety restraint system, is made up of impact sensors, a control module, and the airbags themselves, and this diagnostic tool can detect every electronic parameter to check its health status
And many more ...

2. Complete TPMS Functions for Boost in TPMS Work

On the basis of Autel MK808TS, this tablet automotive diagnostic tool is built with complete TPMS Functions for you to quickly look up the tire sensor IDs from the vehicle's ECU, knowing the running status of Tire Pressure Management System, further improving the diagnostic efficiency.

1). TPMS Check: allows users to activate TPMS sensors to view sensor data-sensor ID, tire pressure, tire temperature, battery condition and sensor location.
* Read and clear diagnostic trouble code of TPMS and view its live data stream;
* Perform the tire pressure and temperature resetting after TPMS maintenance;
2). TPMS Diagnosis: The Diagnosis function is used to check the status of the TPMS system. This function requires connection with the test vehicle.
3). Sensor Programming: The Programming function allows users to program the sensor data to the MX-Sensor and replace faulty sensor with low battery life or the one that is not functioning. There are four options available when programming MX-Sensor:
* Copy by OBD -By using this function, the tablet will program the sensor IDs retrieved from the ECU of the test vehicle to the new MX-Sensors.
* Auto Create-The Auto Create function is used to automatically create a random sensor ID to program a new MX-Sensor.
4). TPMS Relearn: This function is used to write the newly programmed sensor IDs into the vehicle ECU for sensor recognition. There are three ways for Relearn: Stationary Relearn; OBD Relearn.
5). TPMS by OEM Part No.: If the sensor's OEM part number is known, this function is an efficient method to activate and program MX-Sensors.

TPMS Module Retrofitting, Build Everything from Scratch!

TPMS module retrofitting, a function that the other special tool can only dream of! For vehicles that do not have OEM tire pressure module, the tpms diagnostic service tool MK808TS can retrofit your car with an OEM tire pressure module, and also program and relearn the sensors.
Here is the specific step for your reference:

Step 1: Back up the original vehicle data
Step 2: Code the Autel TPMS module
Step 3: Set up the Autel TPMS module on the vehicle following the instruction
Step 4: Program the Autel tire sensors (Note: For the OE tire sensors, this step can be skipped)
Step 5: Activate the Autel tire sensors or OE sensors
Step 6: Relearn the sensors with on-board TPMS module
Once you finish the above steps and sit back to the seat, you will surprisingly find out the pressure of each tire has been shown on the dashboard.

3. Fully-Equipped Popular Functions Like a Repair Garage - One-Stop Solution for most of the Complex Issues

The Autel OBD1 & OBD2 scan tool MK808TS has been equipped with over 28 commonly used special functions to cope with the complex issues hidden in the systems after repairing. Let’s check it out if there’s something you may need on the list:

1) Oil Reset: After the vehicle has been tuned, zero the oil light as well as set the next service mileage.
2) ABS Bleeding: Bleed the brake system when the ABS contains air to restore its braking sensitivity.
3) Gearbox Calibration: Complete the self-learning and calibrate the gearbox with other onboard systems after replacing or repairing.
4) BMS: Reset the monitoring unit of the car battery after replacing battery or battery monitoring sensors.
5) Brake Reset: After or before changing the brake pads, the tool can help you reset the brake sensor.
6) Throttle Matching: Initialize the throttle actuators so that the “learned” values stored on ECU are returned to the default state.
7) Suspension Level Calibration: After replacing the air suspension or adaptive suspension and related parts, you can use it to restore the OE settings of the suspension system.
8) Headlight Matching: initialize the adaptive headlight system.
9) EGR Reset: Reset the diesel engine exhaust gas circulation to restore the original setting.
10) Sunroof Initialization: Initialize the sunroof data to set the sunroof lock off, close in rain, memory function of sliding/tilting sunroof, outside temperature threshold, etc.
11) DPF Regeneration: Clear particulate matter from the DPF filter through continuous combustion oxidation mode to stabilize the filter performance.
12) SAS Calibration: calibrate the steering angle after replacing steering related parts.

How to use Autel MaxiCOM MK808TS?

Step 1: Visit official website:www.autel.com,then create an Autel ID and register the product with device's SN and password.
Step 2: Insert the MaxiVCI Mini into the vehicle's DLC,which is generally located under the vehicle dash.
Step 3: Long press the Lock/Power button to turn on the Diagnostic Table.
Step 4: Pair up the Diagnostic Table with the VCI device via Bluetooth to establish a communication link
When the VCI device is properly connected to the vehicle and the Diagnostic Tablet,the VCI status button at the buttom bar on the display screen shows a green tick at the corner.This indicates your Diagnostic Tablet is ready to start vehicle diagnosis.

How to Update Autel MaxiCOM MK808TS?

Software Update:

Note: Make sure the diagnostic tablet is connected to the internet and the tablet has sufficient battery or is connected to a power source.
Step 1: Tap the Update application button from the Diagnostic Job Menu and the Update screen displays.
Step 2: Check all available updates:
             a) if you want oto update all the items,tap the "Update All" button
             b) if you want to update one or some of the item,tap the "Update" button on the right column of the specific item(s).
Step 3: Tap "Pause" to suspend the updating process.Tap "Continue" to resume.
Step 4: When the updating process is completed,the software will be installed automatically.The previous version will be replaced.

MaxiVCI Mini Firmware Update:

Method 1:
Step 1: Connect the MaxiVCI Mini to a PC using a USB cable.
Step 2: Run the "PC Suite" on the computer which is installed after the installtion of Maxi PC Suite and click MaxiVCI Mini icon on the Device Selection window.
Step 3: The driver will automatically detect the updates of the device.
Step 4: Click "Update" to complete the operation if an update is available.

Method 2:
Step 1: Connect the MaxiVCI Mini with the Diagnostic Tablet using a USB cable.
Step 2: Tap VCI Manager from the Diagnostics Job Menu,and then Update to complete the operation if an update for the MaxiVCI Mini is available.

Difference Between MK808 and MK808TS



  MX808/ MK808 MX808TS/ MK808TS
Basic Diagnostics (all systems in all makes and models)
Read Codes Y Y
Erase Codes Y Y
Live Data Y Y
ECU Information Y Y
Complete OBD Diagnositcs Y Y
Service Functions
Oil Serive Reset Y Y
Parking brake pad relearn after replacement Y Y
Steering Angle Sensor Relearn Y Y
Battery registration and reset Y Y
Diesel particulate filter regeneration Y Y
Tire pressure monitoring system Y
Immobilizer function N N
Complete TPMS functions
Advanced TPMS diagnostics for complete TPMS health check   Y
Activate 98% of all known TPMS sensors   Y
Program AUTEL MX-Sensors   Y
Comprehensive OBD relearn coverage   Y
On-screen relearn procedure   Y
Hardware
Processor Rockchip 3188 Quad-core 1.6GHz Rockchip 3188 Quad-core 1.6GHz
OS Android 4.4.4 Android 4.4.4
Memory 1G + 32G 1G + 32G
Display 7" LCD 7" LCD
Battery 3200 mAh 5000 mAh
Internet Updatable WiFi WiFi
Multilingual Support Y Y
Historical Test Records Y Y
Save and Playback Data Y Y
Print Data via Windows PC or WIFI printer Y Y
Vehicle communication method Wired Wireless (bluetooth)

FAQ:

Q: I'm a Spanish, can I change the default language of MK808TS into Spanish?
A: Sure. Autel MK808TS supports 13 languages for free. Please provide us with the serial number of your MK808TS, we will change the language for you within 6 hours.
Note: The serial number is on the back of the device, it's a 12 digit number. If you cannot find it, please send us a picture, we will check it for you.

Q: Do I have to update MK808TS after 1 year free subscribtion, how much does it cost?
A: To be honest, it depends. You can still use all functions that you were using one year ago without renewal. But please be informed the software of MK808TS keeps updating which means it could cover more car makes and functions. So if you always want to use the newest functions and diagnose the newest car models, I will suggest you to update after 1 year free subscription with 295 bucks charging fees.

Q: How powerful is the TPMS function of MK808TS, can it program other brand sensors except Autel brand?
A: The TPMS function is the key function of MK808TS, it is like top professional TPMS diagnostic scanner, eg. Autel MaxiTPMS TS601/ TS608. Please be informed that Autel MK808TS can only program Autel sensors. I will suggest you to buy Autel sensor(315MHz + 433MHz) which could replace all the OEM sensors in the market and covering 98% vehicles in the world.

Specifications:

Recommended Use Indoor
Operating System Android™ 4.4.4, KitKat
Processor Cortex-A9 quad-core processor (1.4 GHz)
Memory 32GB
Display 7-inch LCD capacitive touchscreen with 1024x600 resolution
Connectivity Mini USB 2.0 USB 2.0
Wi-Fi
HDMI Type A
Micro SD card slot (supports up to 32GB)
Sensors Light sensor for brightness auto adjust
Audio input/output Input: N/A
Output: Beep
Power and Battery 3.7 V/5000 mAh lithium-polymer battery
Charges via 5 VDC power supply
Tested Battery Life Around 7 hours of continuous use
Battery Charging Input 5 V/1.5 A
Power Consumption 600 mA (LCD on with default brightness, Wi-Fi on) @3.7 V
Operating Temp 0 to 55°C(32 to 131°F)
Storage Temp -20 to 60°C (-4 to 140°F)
Operating Humidity 5% - 95% non-condensing
Protocols ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISo11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610, GM UART UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6

Package List:


1pc x Autel MaxiCOM MK808TS
1pc x USB External Power Adapter
1pc x USB Cable (for charging)
1pc x USB Cable (for test)
1pc x MaxiVCI Mini
1pc x Quick reference guide
1pc x Carry case
