Autel MaxiSYS Elite II, As newest emerged model, is upgraded from the Elite/ MS908S Pro/ MK908P and offers a major breakthrough in both hardware and software. As a latest Maxisys Series Latest flagship version scanner, the Autel MaxiSys Elite II is based on the fast and intuitive Android 7.0 OS powered by an Octa-core processor, features a 9.7-inch ultra-high resolutions touchscreen, 4GB RAM & 128GB on-board memory, long-distance wireless communication, and 8 hours of continuous battery life.

2 Years Free Update

Highlights:

1.NEWEST ELITE II, SAME AS MS909 MS919
Autel Elite II scanner has most functions of Elite II Pro/ Ultra/ MS919/ MS909 : One-Stop Diagnosis, ECU Programming&Coding, Programmable module Installation and Personalization, 38+ Service, 10+ High-end Functions, Upgraded Auto Scan 2.0 offers 8X diagnose speed, faster and more accurate than other scanners. ✅Exclusive charging pile allows Elite II to keep power all-day like MS Ultra (Elite II Pro/ MS909/ MS919 WITHOUT). Autel Elite II also support ✅1 Years Free Update ✅NO IP Limitation ✅21+ Languages, also +including Battery Test, WIFI Print, FCA AutoAuth etc

2.J2534 ECU PROGRAMMING ON BENZ & BMW
Autel Elite II can replace existing software/ firmware, reprogram component after replacement, update car software to latest version. Moreover, For Benz, Autel Elite II supports post-programming learning, programming restoration, configuration synchronization, read/ write adjustment value, expert programming etc. For BMW, the programming integration level support up to 2211, supports HTTP programming on some entertainment systems and high-voltage system programming. Note: ECU Programming only for Benz & BMW,

3.ADVANCED ECU ONLINE/OFFLINE CODING
Autel MaxiSys Elite 2 top diagnostic scan tool enables you to perform ECU Coding for 99% vehicles like Audi Benz BMW VW Porsche Chrysler GM. You can refresh hidden function, forbid annoying features, customize OE-settings, match/ learn/ code newly replaced ECU. Online SCN Coding supports big data match and can be automatically calculated, which can quickly verify the accuracy of the SCN.


4.38+ SERVICES, BI-DIRECTIONAL CONTROL
Same as MS919/ MS909, Autel scan tool MaxiSys Elite II has 38+ maintenance for 10,000+ vehicle, such as Oil Reset, EPB, SAS, A/F Setting, Throttle, Suspension, Headlamp, IMMO Keys, Injector Coding, Power Balance, BMS Reset and so on. Bi-directional Control .Autel Elite 2 can transmit command to ECUs and perform active tests like Cooling Fan, A/C Clutch On/Off, Compression Test, ABS Motor Pump, Windows/Wipers/ Sunroof/ Doors Test, Personalized etc.

5.2023 NEW ADDED 10+ HIGH-END FUNCTIONS
To meet the growing demand of repair shops, Autel Elite II for all cars adds 10+ advanced features: ➊Online Parameterization ➋Component Match ➌Power Balanced ➍ VAG Guided ➎IMMO Key ➏Refresh Hidden ➐Pre&Post-Scan share via QR code/ SMS/ Email ➑Autel Cloud Management ➒WIFI Print ➓VIN/ License Plate Scan. To extend service: Autel Elite II connects MV108S/ MV108 for endoscope; connect BT506 for battery test.

6.AUTO SCAN 2.0, FCA Auto AUTH
Autel Elite II is currently the first scanner using Auto Scan 2.0, leap into second-scanning level, average scan speed 3X faster than competitors: GM<8s, BMW Ford VAG Chrysler<10s, etc. Besides, Autel Elite II has full access to protected FCA vehicles now. No need 12+8 adapter just with an authenticated AutoAuth account, Autel Elite 2 can bypass SGW module in 2017 & later FCA cars (Chrysler Dodge Jeep Alfa Romeo Fiat etc.) and perform all set functions.

7.5X LIGHTNING SPEED, TOP HARDWARE
Beyond the reach of most competitors, Autel MaxiSys Elite 2 is design with superior configuration, even better than Elite II Pro. It’s build with Samsung Exynos 8895 Octa-core processor, Android 7.0 OS, 4GB&128GB, 15400mAh larger battery, 2.4&5GHz dual-band WIFI, 5M/16M front/rear camera (Elite II Pro without front camera), suspass Elite II Pro/ Elite/ MS908S Pro/ MK908P. Besides, Autel Elite II has a charging base that Elite II Pro without, keeping all-day working and never worrying about power outages.

8.Quality and After-Sales Guarantee
The Autel MaxiSys Ultra scanner is 100% Original Autel and we ship it from Ship from US Local Distributor,fast and no tax and it comes with 12-month warranty, 1-year free update(after 1 year free update,,if do not update it it will not affect the use of previous functions), lifetime professional tech support.


What's New in Elite II?

1. Hardware and Software Platform Upgrade, a New Operating Experience

1). Samsung Exynos8895 8 core hardware platform.
2). Equipped 5M/ 16M camera.
3). Equipped 4G/ 128G super memory.
4). Equipped 15400mAh battery

2. Support More Expansion Functions, Easy to Manage Various Repair Scenarios

1). Battery detection (works with MaxiBas BT506)
2). Support ADAS calibration, oscilloscope, GPS

3. Support MaxiFix Cloud Service, Efficiency Enhancement at Your Fingertips

1). Support Remote expert service, RealFix, SMS.
2). Device management/report management, data on the cloud without fear of loss

Overview:

1. The most extensive complete system coverage for more than 80 US domestic, Asian and European makes and models.
2. Exceptional OE-Level functionality from comprehensive OBDII diagnostics & services to advanced ECU coding and programming.
3. Uniquely integrated vehicle programming capabilities working with a SAE J2534-1 & -2 compliant vehicle programming pass-thru interface.
4. Automatic system and software updates with real-time push message notifications via internet.
5. Instant remote control tech support anytime, anywhere.
6. Interactive Data Logging sessions enable direct contact with Autel Support for first-hand troubleshooting of diagnostic bugs and errors.
7. One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized.
8. Unique ergonomic design with rubberized outer protection and a rugged internal housing.
9. The most efficient scanner featuring progressive technologies like the Auto VIN Scan & Wi-Fi Data Logging inside a very intuitive and user-friendly interface design. 2x faster than any comparable device and MaxiSys Elite provides extended battery life and power saving.

Vehicle Coverage:

The Latest Maxisys Elite II support almost 90% vehicles all around the world. These multi-functions perform various componet adaptions allowing you to recalibrate or configure certain componet after making repaires or replacement.

1) Supported Vehicle List: AUDI, BENZ, BMW, DACIA, EU FORD, AU Ford, Ford, Holden, LANDROVER, MINI, OPEL, PEUGEOT, RENAULT, SEAT, SKODA, VW, VOLVO, SMART,?JAGUAR, BENZ SPRINTER, SAAB, FIAT, ABARTH, LACIA, ALFA ROMEO, VAUXHALL, MAYBACH, BENTLEY, BUGATTI, PORSCHE,GM, CHRYSLER, FORD,SUZUKI,?KIA, DAWEOO, ISUZU, TOYOTA, SUBARU, SCION, NISSAN, MITSUBISHI, LEXUS, INFINITI, HYUNDAI, HONDA, ACCURA, MAZDA.

2) Supported Protocols:  ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L lins, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939, SAE J1708V

Functions Supported:

1. Full System Diagnosis & Full OBDII functions

Using the additional OEM software, the Maxisys Elite II can be used as a Pass-Thru diagnostics tool as well, which allows users to read and clear Diagnostic Trouble Codes and data log PIDS, collect sensor data and log generic OBDII data, etc.
Similar to many Autel scan tools, the Autel Maxisys Elite II can perform all the OBD II test modes. These include the latest powertrain diagnostic data, freeze frame data, emission diagnostic trouble codes, emissions diagnostic data, oxygen sensor monitoring test results, onboard monitoring tests, VIN, and many more



2. Advanced Oneline ECU Programming & ECU Coding

1) Major Breakthrough:

Autel Elite II supports Volkswagen Audi guide function, BMW F and E chassis hiding function reveal, Code for BMW F chassis, Ford, Mercedes Benz, Chrysler, Toyota, Hyundai, Land Rover, PSA, Renault, Porsche Ford offline programming, online anti-theft for VW, Audi, etc.

2) ECU Programming:

* Replace the existing software/firmware and program the new ECU.
* Load control functions instructions into a specific control module.
* Updating data and operating instructions previously installed in a control module.
* Allow you to perform J2534 programming for Benz / BMW.
* J2534 ECU Programming
J2534 ECU programming of car scanner is designed for BMW and Benz to handle software-controlled drivability issues and emission issues such as fuel efficiency, power loss, fault codes, and durability of mechanical parts, etc.


3) ECU Coding:

ECU coding implies software modifications to a vehicle to allow the use of functions not available in the car. Coding does not imply changing the software but changes preprogrammed options already existent in the software. ECU coding can help you match vehicle parts and on-board systems to strengthen the vehicle performance. MaxiSys Elite II equips with more high-end ECU functions than other types of diagnostic tools.

ECU Coding: Compatible with Mercedes-Benz, BMW, Volkswagen, Audi, China General Motors, Nissan, Land Rover/Jaguar, Haval, etc.

1. Refresh the hidden features (auto start-stop, reverse tilt mirrors, foldable mirrors, and customizing interior lights, etc).
2. Customize the OE settings (setting alarms, door locking, signal, etc).
3. Enhance the vehicle performance (offering the solutions for fuel efficiency, and reduce power loss).


3. Advanced Servcie Functions

Service section is specially designed to provide you quick access to the vehicle systems for various scheduled service and maintenance
performances.

* Oil Reset: Turn off the oil light, reset mileage & service intervals after engine oil is changed
* EPB: Maintain the electronic braking system safely and effectively, deactivating and activating the brake control system, assisting with brake fluid control, opening and closing brake pads, and setting brakes after disc or pad replacement, etc.
* ABS: Bleed the air of a brake system to restore ABS brake sensitivity.
* SAS Calibration: Calibrating steering angle resetting the position of the steering after replacing the steering angle position sensor and the mechanical parts of the steering system
* DPF Regeneration:Through continuous burning of the particulate matter captured in the DPF filter to stabilize the filter performance, turn off DPF light.
* BMS Service: Re-match the control module with the motor sensor to detect the battery more accurately
* Injector Coding: Code the replacement or adjusted injector to more accurately correct the amount of fuel injection of each cylinder.
* Throttle Matching: Relearn their positions through different states (idle, partial throttle, WOT).
More......

4. Autel Cloud Technology

Autel Cloud Technology (MaxiFix Platform, Data Management, Data Feedback) gives you support anytime, anywhere.
1) MaxiFix Application launches the on-line troubleshooter database, which not only provides you virtually all common diagnostic trouble code database for most vehicles, but also serves as a forum allowing you to network with other MaxiSys users, and gives you access to a vast database of repair and diagnostic tips along with proven filed fixes.
2). Data Manager application is used to store, print, and review the saved files.
3). Shop Manager application helps you to manage the workshop information,customer information records, and keep test vehicle history records, which can be a great assist in dealing with daily workshop business and improves customer service


Autel Elite II Automakers' Service Web
​​​​​​
BMW: http://www.bmwtechinfo.com/
Mini: http://www.minitechinfo.com/
Porsche: http://www.porsche.com/
Chrysler, Jeep, Dodge: http://www.techauthority.com/
Ford, Lincoln, Mercury: http://www.motorcraft.com/
Land Rover: http://www.landrovertechinfo.com/
Volvo: http://www.volvotechinfo.com/
Cadillac, Chevrolet, Daewoo, GM, GEO, Pontiac, Buick, Saturn, SAAB, : http://www.gmtechinfo.com/
Acura, Honda: http://www.serviceexpress.honda.com/
Isuzu: http://www.isuzutechinfo.com/
Mazda: http://www.mazdaserviceinfo.com/
Mercedes: http://www.startekinfo.com/
Mitsubishi: http://www.mitsubishitechinfo.com/
Nissan: http://www.nissan-techinfo.com/
Toyota, Lexus, Scion: http://techinfo.toyota.com/
Volkswagen: http://www.erwin.volkswagen.de/erWinVW/
Audi: http://erwin.audi.de/erWinAudi/
Note: When reprogramming on-board, always make sure the vehicle battery is fully charged and in good working condition. During reprogramming there is a risk of having the operation failure if voltage falls below the proper operating voltage. Sometimes a failed operation can be recovered, but there is a chance that failed reprogramming could ruin the control module. We recommend connecting an external battery charger to the vehicle to ensure a successful operation.

Autel MaxiSys Elite vs Autel MaxiSys Elite II vs MaxiSys MS909

1. Hardware Comparison:



Item Autel MaxiSys Elite Autel MaxiSys Elite II Maxisys MS909
CPU Nvidia T40S (4*A15 1.8G) Samsung Exynos8895 8 Core (4*M2 2.3G+4*A53 1.7G) Samsung Exynos88958 Core (4*M2 2.3G+4*A53 1.7G)
EMMC 32GB/64GB /64GB /64GB
DDR 2GB 4GB 4GB
Android System Android4.4 Android 7.0 Android 7.0
LCD 9.7 inch 2048*1536 9.7 inch 2048*1536 9.7 inch BOE 1536×2048
Battery 15400mAH 15400mAH (Elite) 15000mah
Power (9V, 2A) / (12V, 3A) (12V, 3A) (12V, 3A)
TP 10 10 5
Front camera 2M 5M 5M
Rear camera 8M 16M 16M
Microphone connector 1Mic 1Mic (Elite) 1Mic
WiFi module wifi5 wifi5 Dual wifi5
Docking station Yes Yes No
GPS No Yes Yes
Battery tester No Optional Autel MaxiBAS BT506 Optional BT506
VCI MaxiFlash Elite MaxiFlash Elite MaxiFlash VCI

2. Software Functions Comparison:

Item Autel MaxiSys Elite Autel MaxiSys Elite II MaxiSys MS909
Immobilizer IMMO Function No No No
Diagnostic Test Plan Benz BMW VW Audi Jaguar Land rover Benz BMW VW Audi Jaguar Land rover Benz BMW VW Audi Jaguar Land rover




Fault code

guidance

No No Benz BMW VW Audi GM (Cruze)
Technical Bulletin No No Benz BMW VW Audi Ford Chrysler GM Honda
Toyota Jaguar Land rover

Repair case No No Benz BMW VW Audi Chrysler Ford GM Nissan
Toyota Honda Land rover Jaguar
Topology No No Ford Chrysler Nissan Land rover Jaguar Honda
Porsche Toyota Benz Hyundai
Calibration ADAS Yes Yes Yes
Battery test No Yes Yes
Oscilloscope Yes with MP408 Yes with MP408 No
MaxiFix Shop Manager (SMS) Yes Yes Yes
Remote Expert service No Yes Yes
Digital Vehicle Diagnostic Report Yes Yes Yes



Specification:

Operating System Android 7.0
Processor Samsung Exynos 8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53)
Memory 4GB RAM & 128GB On-board Memory
Display 9.7”Retina display with 2048X1536 resolution&Capacitive touch screen
Vehicle Communication Interface(VCI) Maxiflash Elite J2534
Connectivity WiFix2 (802.11 a/b/g/n/ac 2x2 MIMO)
BT v.2.1 + EDR
GPS
USB 2.0 (TWO USB HOST Type A, ONE USB mini device)
HDMI 2.0
SD Card (Support up to 256GB)
Camera Rear:16.0 Megapixel,Autofocus with Flashlight
Front:5.0 Megapixel
Sensors

Gravity Accelerometer

Ambient Light Sensor(ALS)

Audio Input/Output Microphone
Dual Speakers
3-Band 3.5 mm stereo/standard headset jack
Power and Battery 3.7V/15400mAH Lithium-polymer battery
DC/12V/3A Power Supply
Input Voltage DC/12V/3A
Power Consumption Max 20W
Operating Temperature -10 to+55°C
Storage Temperature -20 to+70°C
Protocols ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939, SAE J1708V

Package List:

1pc x Autel MaxiSys Elite II main unit
1pc x main cable
1pc x clipper cable
1pc x USB cable
1pc x ciagrette cable
1pc x MaxiFlash Elite
1pc x AC/DC adapter(12V)
1pc x  product manual
1pc x  docking station
1pc x  carrying case
